Resistance And Air Permeability Tester SC-RT-1202P

Test indexes

Resistance test of filter materials and filter elements.

Air permeability test of filter materials.

Advantages

Controlled by microcomputer makes the instrument much smaller, operated by touch screen makes the operation is simple and intuitive.

Test period is short, and it can be set up freely, the default setting is 10s.

Easy to operate, put the filter material or the filter element  into the fixture, then press the test key, test completed automatically.

Clear data display, built-in printer will print the result immediately.

No vulnerable parts, low maintenance cost.

Applications

SC-RT-1202P is Suitable for quality control of melt-blown, electrostatic cotton, fiber glass, PTFE, other composite filter media and new filter media.

1. Used for resistance and permeability test of filter media.

2. Used for resistance test of filter element.

Technical Parameters

Test flow: 0~120L/min.

Test area for resistance test: 100cm².

Test area for air permeability: 50 cm², 38.3 cm², 20cm², unit of the result is L/(m²·s).

Flow meter accuracy: 2.5%.

Pressure gauge accuracy: 1%

Dimensions: 630mm×220mm×710 mm (L ×W×H).

Environment requirements

Temperature: 10~35°C

Relative humidity: 20~75%RH

Power supply: 220 VAC, 50/60Hz
