SC-W161 Weighing Cabinet is designed for air filter weighing, temporary storage, and natural drying during filter performance and dust-loading tests. The system incorporates an electronic weighing unit and an adjustable suspension structure, allowing different types of air filters to be weighed in a stable and enclosed environment.
| Supported Filter Size Up to | 750 × 800 × 1000 mm |
|---|---|
| Weighing Range | 0–20 kg |
| Scale Division | 0.1 g |
| Operating Modes | Scale / Drying / OFF |
| Weighing Platform Size | 690 × 650 mm |
| Overall Dimensions | 900 × 900 × 1310 mm |
The SC-W161 provides dedicated Scale and Drying operating modes. In Scale mode, the filter load is transferred through the suspension structure to the weighing system for weight measurement. In Drying mode, the suspension structure is separated from the weighing system, preventing prolonged static loading of the weighing sensor while allowing air circulation around the filter.
The cabinet supports bag filters, W-type filters, panel filters, and cylindrical filters, with a weighing range of 0–20 kg and a scale division of 0.1 g. Temperature and humidity can be monitored and recorded during operation.
The weighing data can be transferred to the main filter test system for automatic recording and calculation. The SC-W161 can be used as supporting weighing equipment for both the SC-16890 and SC-29461-1 test systems.
Typical applications include:
